The factory inspection of quick-release boards is a critical quality control link that ensures each product meets pre-set performance, safety, and dimensional standards before leaving the factory. This process follows a systematic and standardized workflow, covering multiple inspection stages from raw material verification to final product testing, leaving no room for potential defects.

The first step in the factory inspection is the incoming inspection of raw materials. Before the production of quick-release boards, inspectors will strictly check the quality of core materials such as metal fasteners, plastic base plates, and connecting components. For metal fasteners, which are key to the quick-release function, inspections include measuring their hardness (using a hardness tester to ensure it meets the specified Rockwell hardness value, usually between HRC 30-40 for wear resistance), tensile strength (through a tensile testing machine to verify that it can withstand the rated pulling force without deformation or breakage), and surface plating quality (checking for plating peeling, rust spots, or scratches via visual inspection and adhesion tests). For plastic base plates, tests focus on material density, impact resistance (using an impact tester to simulate sudden external impacts and ensure no cracks occur), and high-temperature resistance (placing the plate in a constant temperature box at 80°C for 24 hours to observe if there is any deformation or discoloration). Only raw materials that pass all these tests are allowed to enter the production line.

The second stage is in-process inspection, which is carried out simultaneously with the production of quick-release boards. Inspectors use sampling inspection methods (usually following the AQL 1.0 standard, with a sampling ratio of 2%-5% depending on the batch size) to check semi-finished products at key production nodes. For example, after the assembly of the quick-release mechanism, inspectors will test the smoothness of the disassembly and assembly process: they need to complete the disassembly and assembly operation 50 times continuously, and record the force required each time (the normal force range should be 50-150N; if it exceeds this range, it means the mechanism is too tight or too loose). At the same time, dimensional inspections are conducted using precision measuring tools such as calipers (with an accuracy of 0.01mm) and coordinate measuring machines (CMM) to verify whether the key dimensions of the quick-release board, such as the length and width of the base plate, the spacing of the mounting holes, and the height of the fasteners, are consistent with the design drawings (the allowable error is generally within ±0.1mm). Any semi-finished product that fails the in-process inspection will be marked and isolated immediately, and the cause will be analyzed (such as mold wear or assembly errors) to prevent the problem from spreading.

The final stage is the finished product inspection, which is a comprehensive assessment of each quick-release board before packaging. This inspection includes functional testing, load-bearing testing, and appearance inspection. In functional testing, inspectors simulate actual usage scenarios to verify whether the quick-release board can be quickly installed and disassembled under different environmental conditions (such as in a dusty environment or at a low temperature of -10°C) without failure. Load-bearing testing requires placing a weight 1.5 times the rated load on the quick-release board and maintaining it for 4 hours; after the test, the board should not show any structural deformation, and the quick-release mechanism should still work normally. In appearance inspection, each board is checked for surface scratches (the length of a single scratch should not exceed 3mm), color uniformity (using a colorimeter to ensure the color difference ΔE is less than 1.5), and the clarity of logos and labels (the text and patterns should be legible without blurring). Only after all these tests are passed will the quick-release board be affixed with a qualified label, recorded in the inspection report (including batch number, inspection date, inspector's name, and test data), and then packaged for shipment.
